XPOS is a modern and powerful point of sale system designed with Intel® 7th generation Celeron®, Core™ i3 and Core™ i5 processors.

cpu
CPU
  • Intel® Celeron® 3965U; Intel Core™ i3 7100U; Intel Core™ i5 7300U
memory
Memory
  • 4GB Standard, Maximum 32GB (2 x 260-pin DDR4)
storage
Storage
  • 2 x M.2 (B + M Key) SATA III (PCIE)
  • *(Celeron® Supports 1 x PCIE, i3, i5 Supports 2 x PCIE)
connection
Connection
  • 2 x M.2 E Key 801.11ac + BT (Optional)
speaker
Speaker
  • 2 x 2W Internal Speaker
display
Display
  • 15" TFT-LCD / 1024 x 768
touch
Touch
  • Projected Capacitive
brightness
Brightness
  • 400nits (LED) PCAP
power
Power
  • 90W (20V / 4.5A) or 130W (20V / 6.5A) External Adapter
port
Port
  • 1 x USB 3.0 Type A
  • 1 x USB 2.0 Type A
  • 1 x USB DP (Reserved for 2nd Display)
  • 1 x FEC DP (Customer Display or 2nd Display)
I/O on Base
I/O on Base
  • 2 x External RJ45 (COM3, COM4)
  • 4 x USB 2.0 Type A
  • 1 x USB DP (2nd Display)
  • 1 x RJ11 (12V / 24V) Supports 2 Cash Drawers
  • 1 x RJ45 LAN
  • 1 x 20V DC-in
certification
Certification
  • FCC Class B / CE
os
OS
  • Windows 10 Pro, Windows 10 IoT Enterprise
appearance
Appearance
  • Aluminum Die-casting + Plastic
  • Galaxy Grey or Silver
dimension
Dimension
  • Product: 342.5 x 332 x 231.74 mm
  • Carton: 550 x 215 x 470 mm
Processor
  • Intel® Celeron® 3965U
  • Intel Core™ i3 7100U
  • Intel Core™ i5 7300U
Memory
  • 4GB DDR4 2666 MHz
  • 8GB DDR4 3200 MHz
Colors
  • Black
  • Silver
  • Grey
